2×2 HDMI MATRIX SWITCH

$289.00

Model: SW-HDM-2×2
Add to Wishlist

Description

Overview

Avenview SW-HDM-2×2 Matrix Switcher allows the user to display and switch HDMI video/audio signals from any of its two inputs and simultaneously display it on any of its two HMDI outputs and switch between. SW-HDM-2×2 Matrix Switcher can transfer Deep Color video and bit stream digital audio with maximum performance and it supports HDMI 1.3, HDCP 1.1 and DVI 1.0. This unit can be easily controlled with RS-232 and IR remote.

Features

• HDMI 1.3, HDCP 1.1 and DVI 1.0 compliant.
• Supports digital video formats in Deep Color 12bit and new lossless compressed (Dolby TrueHD, Dolby Digital Plus and DTS-HD Master Audio) digital audio.
• HDMI input compensation, clock phase adjustment, and jitter free.
• Supports input source LED indicators on each output.
• Compatible with all HDMI sources and displays.
• Supports a wide range of PC and HDTV resolutions from VGA to UXGA and 480i to 1080p.
• Dolby Digital, DTS digital audio transmission (32-192 kHz Fs sample rate).
• Supports LPCM7.1 channels output from each independent HDMI ports.
• HDMI cable distance testing showed that with 1080p/8-bit or 12-bit resolution, the input/output distance can be up to 15/15 meters.
• Switchable EDID function for choosing the desired resolution to display.
• Define HDCP, HDMI and DVI source. The LED will turn on to define the input source’s format.
• HDMI signal re-timed, and level-compensated.
• Supports RS-232 control.
• Supports IR remote control and IR extender.HDMI 2.0a compliant;



Specifications

ITEM

DESCRIPTION

UNIT

SW-HDM-2X2

UNIT DESCRIPTION

Matrix Switcher

HDMI COMPLIANCE

Yes

HDCP COMPLIANCE
Yes

INPUT PORTS

2 x HDMI

OUTPUT PORTS
2x HDMI
HDMI AUDIO OUTPUT

PCM2, PCM5.1, PCM7.1, Dolby5.1, DTS5.1,
DD+, D-TrueHD, DTS-HD

HDMI CONNECTOR

Type A [19-pin female]

FREQUENCY BANDWIDTH
2.25Gbps (single link)

HDMI IN/OUT DISTANCE

1080p 8bit/12bit (15M)

HDMI RESOLUTION

480I~1080p 50/60, 1080p 24, VGA~UXGA

DVI RESOLUTION

480I~1080p 50/60, 1080p 24, VGA~UXGA

CONTROL

RS 232, IR Remote,

POWER SUPPLY

5V / 3.2A DC (uS/Eu standards, CE/FCC/UL certified)

POWER CONSUMPTION
9 W
DIMENSIONS (L X W X H)
9.4” x 6.6” x 1.7”

WEIGHT

2.7 lbs

ENVIRONMENTAL

OPERATING TEMPERATURE

32° ~ 104°F (0° to 40°C)

STORAGE TEMPERATURE

-4° ~ 140°F (-20° ~ 60°C)

ESD PROTECTION
Human body model — ±8kV (air-gap discharge) & ±4kV (contact discharge)

RELATIVE HUMIDITY

20~90% RH (no condensation)

  • Model: SW-HDM-2×2
  • Shipping Weight: 5.9lbs

FAQ Warranty & RMA Product Registration Avenview Tech Support

Additional information

Weight 1.22 kg
Dimensions 23.88 × 16.8 × 4.32 cm
