2×8 HDMI Extender / Splitter over Single CAT5 Cascading Distribution Amplifier

2x8 HDMI Extender / Splitter over Single CAT5 Cascading Distribution Amplifier
2×8 HDMI Extender / Splitter over Single CAT5 Cascading Distribution Amplifier

$599.00

Model:  HDM-C5SP-8SR
Add to Wishlist
Categories: , , , Tag:

Description

Overview

The Avenview HDM-C5SP-8SR (old model: HDMI-C5SP-8SR) HDMI over Single CAT5 Cascading Distribution Amplifier provides the most flexible solution by which the high definition video and high quality audio can be transmitted to different locations over a long distance.

The devices are cascadable, allowing you to extend HDMI compliant displays almost anywhere. The 2 input HDMI source (only 1 input can be used at a time) can be duplicated and distributed to up to 8 HDMI enable displays through cost effective Cat-5/5e cables and RJ-45 to HDMI mini-extenders HDM-C5-R-M (old model: HDMI-C5-R-M)


With the built in equalization, the input HDMI cable can be extended up to 20 meters (66 feet) long under Full HD, and make the overall transmission distance superior than regular HDMI splitters or matrix switches in the market.

Features

  • Silicon Image chipset embedded for best quality, compatibility and reliability
  • HDMI 1.3c compliant
  • HDCP compliant
  • Regenerates the HDMI signal
  • Acts as 2X1 HDMI Switch and 1X8 HDMI over CAT5 Splitter
  • HDMI video distribution to up to 7 displays and one CAT5e Receiver or cascade to another HDMI-C5SP-8SR
  • Supports default HDMI EDID and has the ability to learn the EDID of the displays
  • Input up to 15m (50ft) using HDMI cables
  • Extends up to 60m (200ft) (720p / 1080i) of output CAT5/6 cable
  • Outputs up to 15m (50ft) using HDMI cables
  • Pure unaltered uncompressed 7.1ch digital HDMI over LAN cable transmission
  • Allows cascading
  • 1U rack mountable with interlocking power adapter for fixedness
  • Perfectly integrated with other HDMI-C5XD Series products

Technical Specifications

ITEM

DESCRIPTION

UNIT

HDM-C5SP-8SR

UNIT DESCRIPTION

2×8 HDMI 1.3 Transmitter / Splitter over CAT5 / CAT6 – Cascadable

HDMI COMPLIANCE

HDMI 1.3c

HDCP COMPLIANCE

Yes

VIDEO BANDWIDTH

Single Link 225 Mhz (6.75Gbps)

VIDEO RESOLUTIONS

480i / 480p / 720p / 1080i / 1080p60

HDMI TRANSMISSION RANGE

Full HD: (1080p) ~ 40meter (130feet) (CAT5e) / 50meter (165feet) (CAT6)
HD: (720p/1080i) ~ 50meter (165feet) (CAT5e) / 60meter (200feet) (CAT6)

AUDIO SUPPORT

Surround Sound (up to 7.1 ch) or Stereo Digital Audio

INPUT TMDS SIGNAL

1.2 Volts (peak-to-peak)

INPUT DDC SIGNAL

5 Volts (peak-to-peak, TTL)

ESD PROTECTION

[1] Human body model — ±15kV [air-gap discharge] & ±8kV [contact discharge]
[2] Core chipset — ±8kV

INPUT CONNECTORS

1 x HDMI
1 x RJ45

OUTPUT CONNECTORS

1 x RJ45
7 x HDMI

DIMENSIONS

13″ x 4.3″ x 1.7″

POWER SUPPLY

5V 4A DC

POWER CONSUMPTION

13 Watt (max)

ENVIRONMENTAL
OPERATING TEMPERATURE

0°~40°C (32°~104°F)

STORAGE TEMPERATURE

-20°~60°C (-4°~140°F)

RELATIVE HUMIDITY

20 ~ 90% RH (no condensation)

Package Contents

  • 1 x HDM-C5SP-8SR
  • 2 x Rack-mounting Ears
  • 1 x Power Adapter (+5VDC, 4A)
  • 1 x User’s Manual

HDMI Extender over CAT5 Application Diagram
HDMI Extender over CAT5 Application Diagram

User Guides

Avenview 2x8 Port HDMI 1.3 Extender / Splitter over Single CAT5 / CAT6 Cascadable User GuideAvenview 2×8 Port HDMI 1.3 Extender / Splitter over Single CAT5 / CAT6 Cascadable User Guide



FAQ Warranty & RMA Product Registration Avenview Tech Support
MICROSITE

Additional information

Weight 2.86 kg
