MLT-EDGEPRO-2X2 4K30 Edge Blending Video Wall Processor

$3,599.00

 Model : MLT-EDGEPRO-2X2

Out of stock

Add to Wishlist

Description

Overview

The Avenview MLT-EDGEPRO-2X2 is a dual output multi format input professional curved screen edge blending processor. It was designed for advanced edge blending as well as image warping, stacking, projection mapping, irregular video wall, passive 3D and much more.

5 inputs and 2x HDMI outputs are integrated in MLT-EDGEPRO-2X2. Input ports support up to 2560×1600 / 3840×1080 @60Hz and 4K 3840×2160 UHD @30Hz resolution with 4:4:4 full color sampling. It is integrated with 10-bit high end processor with motion adaptive de-interlace, 3:2/2:2 pull-down and supports non-VESA standard input timing.
The MLT-EDGEPRO-2×2 features warp technology. User can use front panel keypads, IR controller and PC control software to perform edge blending and advanced geometry alignment up to 17×17 grids. Independent color (white balance) adjustment for each projector, overlapped area colour correction and non-overlapped area
black level uplift are also standard functions in the MLT-EDGEPRO-2X2. Users can see real time geometry and colour adjustments and get live on-screen optimized results.
HDMI loop out supports daisy chain connection up to 3840×1080 @60Hz or 4k/2k @30Hz and allows a larger display area with multiple MLT-EDGEPRO-2X2 cascaded. Video wall function in MLT-EDGEPRO-2X2 allows cropping and allocate source image for each projector. Complete curved edge blending can be achieved without PC, video extender or a splitter.
With MLT-EDGEPRO-2X2, users can replace high end projectors with low cost projectors without lens shift, warp and edge blending features. It provides easy configuration, lower cost, reliable and flexible solution.



Features

•Two outputs advanced curved screen edge blending processor;
•Five multi-input formats supporting resolutions up to 4K@30;
•Image warping, stacking, projection mapping, irregular video
•wall and passive 3D features;
•Embedded advanced warp technology;
•Sophisticated geometry alignment up to 17×17 grids;
•Independent color adjustment for each connected projector;
•Advanced overlapped area color correction;
•HDMI Loop out for daisy chain connection; multiple cascaded devices produce a single large displayed image;
•Multi control options using front panel keypads, IR and PC control software;
•10 bit 4:4:4 full sampling processing;
•Video wall function with PIP, zoom, pan, overlap features;
•Selectable EDID menu.



Specifications

ITEM

DESCRIPTION

UNIT

MLT-EDGEPRO-2X2

UNIT DESCRIPTION

Curved Screen Edge Blending Processor

INPUT PORTS

2x HDMI, 1x VGA, 1x DisplayPort, 1x DVI, 1x Micro-USB, 1x RS232 1x RJ45

OUTPUT PORTS

2x HDMI, 1x HDMI Loop Out

OUTPUT RESOLUTION

2x HDMI up to 1920×1200@60, 1x HDMI Loop out up to 3840×2160@30

INPUT RESOLUTION
Support 4k/2k @30Hz with 4:4:4 sampling , 2560×1600@60, 3840×1080@60, 1920×1080@60
HDCP VIDEO COMPLIANCE

1.3

CASCADABLE

Yes

DIGITAL AUDIO SUPPORT

LPCM, Dolby Digital/Plus/EX, Dolby True HD,DTS,DTS-HD Master

VIDEO LOOP OUT

Yes

PRESET PROFILES

Up to 10 preset output modes

BEZEL COMPENSATION

Yes. (in video wall mode)

CONTROL
IR Remote, RS 232, front panel, Ethernet

DIMENSIONS (L X W X H)

17.3” x 7.4” x 1.7”

POWER SUPPLY

12V 3A DC / 110-240V

POWER CONSUMPTION
TBA
LED
Front Panel Indicator

WEIGHT

5.18 lbs

ENVIRONMENTAL

OPERATING TEMPERATURE

32° ~ 104°F (0° to 40°C)

STORAGE TEMPERATURE

-4° ~ 140°F (-20° ~ 60°C)

ESD PROTECTION
Human body model — ±8kV (air-gap discharge) & ±4kV (contact discharge)

RELATIVE HUMIDITY

20~90% RH (no condensation)



Avenview HDBaseT 4K 8x8 matrix switcher


Control Software

Edgepro Tool EdgePro PC Tool
FAQ Warranty & RMA Product Registration Avenview Tech Support

Additional information

Weight 2.35 kg
Dimensions 43.9 × 18.8 × 4.3 cm
