Description

Overview

Name: 4K30 Video Wall Processor with Customizable Layout Shapes
SKU: 935
Availability: InStock

The Avenview MLT-PROWALL-4K quad multi-input videowall controller is a four channel high end 10-bit processor with 3D motion adaptive de-interlace, low angle smooth algorithm and 3:2/2:2 film mode processing for creative irregular video wall layouts.

This video wall is designed with 3 input & 4 output ports with the capability to select up to 256 pre-defined display modes, settings can be achieved through Dip switch settings on front panel. Pre-defined display modes include multiple rotation angles, position and arrays. Customized layouts can be added from the OSD menu. Dual contents can be displayed on the video wall at the same time. One HDMI 4k/2k loop out port is available for daisy chain connection while cascading with multiple units of MLT-PROWALL-4K for video wall larger than 4 Displays. The MLT-PROWALL-4K is designed to display 3-4 panles as one display unit based on full HD display with the same size and resolution.

Features

• Four Output Video Wall Controller;
• 1080P output resolution on each port;
• Supports 4K/2K Input resolution with no compression;
• 10 bits 4:4:4 full bandwidth sampling with 3D de-interlace;
• Pre-defined display profiles;
• Selectable preset bezel correction;
• PIP/POP function;
• Front panel DIP Swtich selections, no PC required;
• Controlled through RS 232 or IR remote;
• HDMI Loop out port for daisy chain connection;
• Cascade with multiple MLT-PROWALL-4K for expansion;
• Supports display flipping and rotation;
• Bezel Compensation;
• 256 Preset Layouts.

Specifications

ITEM	DESCRIPTION
UNIT	MLT-PROWALL-4K
UNIT DESCRIPTION	Quad Multi-Input Videowall Controller
HDCP COMPLIANCE	Yes
VIDEO PROCESSOR	10-bits
INPUT RESOLUTION	Support 4k/2k @30Hz, 1080p @120Hz, 2560×1600 / 3840×1080 @60Hz input with 4:4:4 sampling
OUTPUT RESOLUTION	Support 4k/2k @30Hz (Combined screens), 1080p @120Hz, 2560×1600 / 3840×1080 @60Hz input with 4:4:4 sampling
PRESET LAYOUTS	256 Layouts
CASCADABLE	Yes
DIGITAL AUDIO SUPPORT	LPCM, Dolby Digital/Plus/EX, Dolby True HD,DTS,DTS-HD Master
INPUT	1 x HDMI, 1 xDVI, 1x DP
OUTPUT	4 x HDMI Type A (19 pin female)
4K2K HDMI LOOP OUT	Yes
CONTROL	IR Remote, RS 232, DIP Switches, Ethernet (optional external)
DIMENSIONS (L X W X H)	12” x 6.2” x 1.3”
POWER SUPPLY	12V 3.33A DC
POWER CONSUMPTION	TBA
LED	Front Panel Indicator
RACK MOUNTABLE	Yes
WEIGHT	5.7 lbs
*ENVIRONMENTAL*
OPERATING TEMPERATURE	32° ~ 104°F (0° to 40°C)
STORAGE TEMPERATURE	-4° ~ 140°F (-20° ~ 60°C)
ESD PROTECTION	Human body model — ±8kV (air-gap discharge) & ±4kV (contact discharge)
RELATIVE HUMIDITY	20~90% RH (no condensation)
