4X1 HDMI 4K60 Switcher

$459.00

Model:  SW-HDM2-T4K-4X1
Add to Wishlist

Description

Overview

Avenview 4×1 HDMI 4K@60 Switcher allows the transmission of video and multi-channel digital audio at 4K resolution. It allows the transmission of 18Gbps HDMI signal from any of its four HDMI 2.0 source inputs to one HDMI 2.0 with HDCP 2.2 support connected display. With supports 4K2K@60, 48-bit Deep Color, HDR (High Dynamic Range) audio and other features defined by HDMI 2.0 specifications. This device can be operated and controlled easily through front panel buttons, IR remote control, RS-232,
Telnet or Web GUI controls.

Features

• HDMI 2.0 (with HDR and 4K@60/UHD supported) and HDCP 2.2 compliant;
• Select any one of four HDMI 2.0 sources and display on a HDTV display with fast switching between sources;
• Full HD Up to 1080p/60 up to 75ft
• Supports HD resolutions up to UHD (3840×2160@24/25/30/50/60 & 4K (4096×2160 @24/25/30/50/60Hz)
• Supports HDR (10 bit 4:2:0)
• Supports HDMI 2.0 data rate from 18Gbps and ‘Deep Color’ up to 1080p/48-bit
• Supports selection of Standard (Fixed) or TV (Downstream) EDID settings Supports Audio pass-through of High-definition Audio formats PCM 2/5.1/7.1CH, Dolby Digital 2~5.1CH, DTS 2~5.1CH, Dolby Digital Plus, Dolby TrueHD, Dolby Atmos and DTS-HD Master Audio
• Supports IR Remote, Telnet, Web GUI control and RS-232



Specifications

ITEM

DESCRIPTION

UNIT

SW-HDM2-T4K-4X1

UNIT DESCRIPTION

4X1 4K@60/UHD HDMI Switcher with IR/RS-232/ Support

HDCP

YES

VIDEO BANDWIDTH
600 MHz (6 Gbps)

SUPPORTED RESOLUTION

480i~UHD (3840×2160@24/25/30/50/60 & 4K (4096×2160@24/25/30/50/60Hz)

AUDIO SUPPORT

PCM 2/5.1/7.1CH, Dolby Digital 2~5.1CH, DTS 2~5.1CH, Dolby Digital Plus,
Dolby TrueHD,Dolby Atmos and DTS-HD Master Audio

ESD PROTECTION

Human body model — ± 12kV (air-gap discharge) & ±8kV (contact discharge)

INPUT

4 x HDMI
1 x IR
1 x RS 232
1 x ETHERNET
1 x USB (Factory use)

OUTPUT
1 x HDMI
HDMI CONNECTOR

Type A (19 pin female) Sampling Rate 32kHz ~ 192 kHz

IR FREQUENCY

38kHz

DIMENSIONS (L X W X H)
9.4” x 4.0” x 1.7”
240 mm (L)× 104 mm (W)× 43mm (H)

WEIGHT

0.79kg /1.74lbs

POWER SUPPLY

5VDC /2.6A
(US/EU standards, CE/FCC/UL certified)

POWER CONSUMPTION

5.83W Stanby Mode (1.1W)

ENVIRONMENTAL

OPERATING TEMPERATURE

32° ~ 104°F (0° to 40°C)

STORAGE TEMPERATURE

-4° ~ 140°F (-20° ~ 60°C)

RELATIVE HUMIDITY

20~90% RH (no condensation)


  • Model: SW-HDM2-T4K-4X1
  • Shipping Weight: 5.9lbs


DVI-SPLITPRO-4X Advanced Quad Screen Multiviewer Application Diagram

FAQ Warranty & RMA Product Registration Avenview Tech Support

Additional information

Weight 0.79 kg
Dimensions 24 × 10.4 × 4.3 cm
