4X4 HDMI 4K60 Matrix Switcher

$999.00

Model:  SW-HDM2-T4K-4X4
Add to Wishlist

Description

Overview

The SW-HDM2-T4K matrix switcher features four HDMI inputs and four HDMI outputs. It provides true matrix routing for HDMI signals. It supports the transmission of video (resolutions up to 2160p@60Hz Ultra HD 4:4:4) and supports high resolution digital audio formats such as LPCM 7.1CH, Dolby TrueHD, Dolby Digital Plus and DTS-HD Master Audio. It works with Blue-Ray players, Set-Top boxes, Home Theater PCs, and game consoles. Inputs and outputs switching are accessible at all times via IR Remote Control, RS-232, TCP/IP or the selection buttons on the front panel. This device supports all HDMI 3D formats.

Features

– HDMI2.0, HDCP2.2/HDCP1.4 compliant
– Support video format up to 4K2K@60Hz with 24bit RGB/YCbCr 4:4:4/YCbCr 4:2:2, and up to 4k2k@60Hz with 12bit YCBCR 4:2:0
– Support color space conversions among RGB, YCbCr4:4:4, YCbCr4:2:2 and xvYCC video formats
– Support all HDMI 3D formats up to 2160p@30
– Support high resolution VESA mode video format up to QSXGA@60Hz
– Support reception of any audio data conforming to the HDMI specification such PCM at up to 192kHz, compressed audio (IEC 61937), DSD, DST, DTS and HBR
– Support simultaneous HDMI Coax and L/R audio outputs
– Support smart EDID management
– Support RS-232, remote control, on-panel control and TCP/IP Control



Specifications

ITEM

DESCRIPTION

UNIT

SW-HDM2-T4K-4X4

UNIT DESCRIPTION

4X4 HDMI 4K60 Matrix Switcher

HDMI COMPLIANCE

2.0

HDCP COMPLIANCE
2.2

INPUT PORTS

4 x HDMI, 1×IR Receiver, 1×RS-232, 1xRJ-45 (Control)

OUTPUT PORTS
4 x HDMI, 4×Toslink, 4×L/R
HDMI AUDIO OUTPUT

PCM2, PCM5.1, PCM7.1, Dolby5.1, DTS5.1,
DD+, D-TrueHD, DTS-HD

HDMI CONNECTOR

Type A [19-pin female]

3.5mm CONNECTOR
IR Receiver

HDMI IN/OUT DISTANCE

1080p 8bit/12bit (15M)
4K (5M)

HDMI RESOLUTION

480i, 576i, 480p, 576p, 720p, 1080i, 1080p24/30/50/60, 2160p24/25/30/50/60;

CONTROL

RS 232, IR Remote, Ethernet

POWER SUPPLY

12V/2.5A DC (US/EU standards, CE/FCC/UL certified)

POWER CONSUMPTION
9 W (max)
DIMENSIONS (L X W X H)
17.2” x 8” x 1.8

WEIGHT

4 lbs

ENVIRONMENTAL

OPERATING TEMPERATURE

32° ~ 104°F (0° to 40°C)

STORAGE TEMPERATURE

-4° ~ 140°F (-20° ~ 60°C)

ESD PROTECTION
Human body model — ±8kV (air-gap discharge) & ±4kV (contact discharge)

RELATIVE HUMIDITY

20~90% RH (no condensation)


  • Model: SW-HDM2-T4K-4X4
  • Shipping Weight: 5.9lbs


DVI-SPLITPRO-4X Advanced Quad Screen Multiviewer Application Diagram

FAQ Warranty & RMA Product Registration Avenview Tech Support

Additional information

Weight 1.81 kg
Dimensions 43.7 × 20.32 × 4.57 cm
