Features

• H.264 video decoder;
• Transmits audio and video from ethernet port to HDMI;
• Streams media through LAN or WAN;
• Input Resolutions: From 640×480@60Hz to 1080p@24/25/30/50/60Hz;
• Can be used using the Encoder only with a compatible decoding software over IP;
• Receive TS data with unicast or multicast method;
• Supports RTSP protocol;
• Output Resolution: From 640×480@60Hz to 1080p@24/25/30/50/60Hz;
• Supports audio format including LPCM or AAC standard;
• Displays can be controlled using RS-232 or CEC;
• Telnet CLI and Web UI supported;
• Supports static IP, DHCP and AutoIP;
• Video Bitrate: 2m~30Mbps;
• AAC Audio Bitrate: 32~240Kbps;
• LPCM Audio Bitrate: 1.6Mbps;
• Supports video timing up to 1920×1080@60Hz and 1920×1200@60Hz;
• Low Latency Mode: 120ms end-to-end latency.

ITEM

DESCRIPTION

UNIT

HDM-XTRM-IP-SET

UNIT DESCRIPTION

H.264 IP CAPTURE TO HDMI

HDCP COMPLIANCE

Yes

VIDEO BANDWIDTH

2M~30Mbps

SUPPORTED RESOLUTIONS

640×480@60, 800×600@60, 1024×768@60, 1280×768@60, 1280×800@60, 1280×1024@60, 1360×768@60, 1366×768@60, 1440×900@60, 1400×1050@60, 1600×1200@60, 1680×1050@60, 1920×1200@60, 720×480 (480p)@60, 720×576 (576p), 1280×720 (720p30), 1280×720 (720p50), 1280×720 (720p60), 1920×1080 (1080p24), 1920×1080 (1080p25), 1920×1080 (1080p30), 1920×1080 (1080p50), 1920×1080 (1080p60)

AUDIO SUPPORT

LPCM 7.1CH, Dolby TrueHD, and DTS-HD Master Audio

INPUT

4×HDMI/DVI, 5×IR Receiver, 1×RS-232, 1×RJ-45 , 1×Mini
USB Type B (For firmware updates only)

OUTPUT

4×CAT5e/6/7, 5×IR Blaster

HDMI CONNECTOR

Type A (19 pin female)

SWITCHING SPEED

±8 kV (air-gap discharge)
±4 kV (contact discharge)

ESD PROTECTION

32 Lbs

DIMENSIONS (L X W X H)

17″x 10″x 1.8″

POWER SUPPLY

24 V/2.7 A DC (US/EU standards, CE/FCC/UL certified)

POWER CONSUMPTION

35W

ENVIRONMENTAL

OPERATING TEMPERATURE

32° ~ 104°F (0° to 40°C)

STORAGE TEMPERATURE

-4° ~ 140°F (-20° ~ 60°C)

RELATIVE HUMIDITY

20~90% RH (no condensation)
