FO-DP-XX-MM DP Extender Fiber

4K@60Hz HDR DisplayPort cable over Fiber Optic

SKU FO-DP-XX-MM Category Clearance Tags cable, display port, displayport, DPCP, Extender, Fiber, Fiber Optic, HDCP

Overview

Avenview FO-DP-XX-MM Series with fiber optic cable system lets you extend DisplayPort digital signal up to 65 meters (210 feet) at WQXGA (2560×1600) resolution.Examples include:

Video wall System
Large LED Sign Board
Medical Imaging Equipment
Airplane On-board Video System
Home Theater
TV Broadcast Station
Auditorium
Conference Room Video Equipment

Features

High Speed and long distance transmission by Optical fiber
Compatible with DisplayPort standard v1.1a
HBR(High Bit Rate) Cable Assembly (up to 2.7Gbs Data Rate)
Use Extender Power
Supports up to WQXGA (2560 x 1600) resolution
AUX and Hot-Plug channels are transmitted by copper line
DPCP & HDCP compliant(DPCP & HDCP are not part of the DisplayPort standard)

Technical Specification

ITEM	DESCRIPTION
SINGLE BANDWIDTH	10bit Deep Color / 60Hz
CONNECTORS	20 pin DisplayPort Plug
SUPPORTED RESOLUTIONS	up to 2560 x 1600 @ 65 meters (210 Feet)
OPTICAL SOURCE	4 ch 850nm Multi-Mode VCSEL
ENVIRONMENTAL
OPERATING TEMPERATURE	32°F to 122°F (0°C to 50°C)
STORAGE TEMPERATURE	-4F to 158F (-20C to 70C)

UNITS	UNIT DESCRIPTION	Length
FO-DP-10-MM	DisplayPort Fiber Optical Cable, 33 Feet	10 Meters (33 Feet)
FO-DP-15-MM	DisplayPort Fiber Optical Cable, 49 Feet	15 Meters (49 Feet)
FO-DP-20-MM	DisplayPort Fiber Optical Cable, 66 Feet	20 Meters (66 Feet)
FO-DP-25-MM	DisplayPort Fiber Optical Cable, 82 Feet	25 Meters (82 Feet)
FO-DP-30-MM	DisplayPort Fiber Optical Cable, 100 Feet	30 Meters (100 Feet)
FO-DP-50-MM	DisplayPort Fiber Optical Cable, 165 Feet	50 Meters (165 Feet)
FO-DP-65-MM	DisplayPort Fiber Optical Cable, 246 Feet	65 Meters (210Feet)
