Overview

Avenview FO-HDM-1000M-EMI (Old Model number: FO-HDMI-1000M-EMI) optical HDMI extension module over 1SC Type Fiber Optic Cable, is designed to let digital flat panel display extend over 1000 meters away from host based on HDMI standard by optical transmission technology. Its small package and transmit up to four video and one low-speed lane, while simultaneously receiving one low-speed signal, all on one multimode fiber.

Features

High Speed and long distance transmission by 1 channel SC type Multi-mode Fiber
Supports resolution up to HDTV/1080P, PC/WUXGA(1920×1200)
Transmit up to 300m (1000 feet) at 1920 x 1200 by multi-mode SC Type one fiber optic cable
Transmit up to 300m (1000 feet) at 1920 x 1080 by multi-mode SC Type one fiber optic cable
TMDS video signal and EDID data is transmitted by 1 channel multimode optical fiber
HDCP support by DDC channel
Supports 12Bit Deep Color
Small size for insertion into internal system
Optional external power supply (Automatic power switch is included.)

Technical Specification

ITEM	DESCRIPTION
UNITS	FO-HDM-1000M-EMI Transmitter	FO-HDM-1000M-EMI Receiver
UNIT DESCRIPTION	HDMI Fiber Optic Transmitter	HDMI Dual Link Fiber Optic Receiver
HDMI COMPLIANCE	HDMI
HDCP COMPLIANCE	HDCP
VIDEO BANDWIDTH	2.25Gbps
SUPPORTED RESOLUTION & DISTANCE	WUXGA 1920 x 1200 @ 300 meters ( 1000 feet) 1080p 1920 x 1200 @ 300 meters (1000 feet)
OPTICAL CONVERTOR	4 Ch 850 nm Transmit OSA 911nm, 1 Ch VCSEL 980nm, 1 Ch PIN P/D Diode	4 Ch 850 nm Transmit OSA 911nm, 1 Ch VCSEL 980nm, 1 Ch PIN P/D Diode
HDMI CONNECTOR	HDMI Type A Plug
OPTICAL CONNECTOR	1 SC Connector
DIMENSION	10.7″ x 1.2″ x 0.5″
