HDM-C6IP-SET

Overview

HDM-C6IP-SET, HDMI extender set is designed to  extend your HD display with the resolutions of 1080p/60Hz up to 328 feet (100  meters) away from your HDMI or DVI-D source.. Thanks to the use of the TCP/IP  protocol, you can transfer your high-definition video over an existing TCP/IP  network. See below three examples: A :-The Tx and Rx units can extend 100 meters over a single CAT5/6 cable  connection point to point. B:- The Tx can be connected to a switch to establish a IP address  therefore sending 1080p video signals to Multiple Rx connected to the switch to the  desired displays. BONUS up to 150 Displays with single Tx. C:- Multiple Tx can be connected to a Managed Switch with IGMP/VLAN creating a STATIC  address therefore sending different 1080p video signals to more than one Rx connected to the Managed Switch with IGMP/VLAN to  the desired displays. Thus establishing a Matrix Function.

Features

• Silicon Image chipset embedded for best quality, compatibility and reliability
• HDMI compliant
• HDCP compliant
• EDID
• Regenerates the HDMI signal
• Extends HDMI up  to 100m/120m over single CAT5E/6
• Supports  resolution HDTV / 1080Pp/60Hz, Vesa (1920 x 1080)
• Supporting the point to point transmission function currently which  can be expanded to the multi-point to point transmission function.
• Pure unaltered uncompressed 7.1ch digital HDMI over LAN cable transmission
• Allows upto 150 Receivers to single Transmitter

Network Switch: Avenview recommends Cisco 100 Series (eg. Cisco SG110D) or other non-PoE compatible switches.

Technical Specifications

ITEM	DESCRIPTION
UNITS	HDM-C6IP-S	HDM-C6IP-R
UNIT DESCRIPTION	HDMI Transmitter	HDMI Receiver
HDMI COMPLIANCE	HDMI
HDCP COMPLIANCE	Yes
VIDEO BANDWIDTH	M-JPEG Technology to process image compressing GIGABIT (10/1000) over LAN
INPUT VIDEO RESOLUTIONS	480i@60Hz, 480p@60Hz, 576i@50Hz, 576p@50Hz, 720p@50/60Hz,                                        1080i@50/60Hz, 1080p@50/60Hz
OUTPUT VIDEO RESOLUTIONS	480p / 720p / 1080p60
HDMI TRANSMISSION	Full HD: (1080p) — 95 meter (298 feet) ( CAT5e/6) / 100 meter (328 feet) (CAT6)
AUDIO SUPPORT	Surround Sound (up to 7.1 ch) or Stereo Digital Audio
ESD PROTECTION	[1] Human body model — ±15kV [air-gap discharge] & ±8kV [contact discharge] [2] Core chipset — ±8kV
INPUT	1 x RJ45 / 1 x HDMI
OUTPUT	1 x RJ45 / 1 x HDMI
DIMENSIONS LxWxH	110mm x 58mm x 26mm (4.3″ x 2.2″ x 1″)
POWER SUPPLY	2 X DC 5V/1A
POWER CONSUMPTION	3W Max Each
ENVIRONMENTAL
OPERATING TEMPERATURE	0°~40°C (32°~104°F)
STORAGE TEMPERATURE	-20°~60°C (-4°~140°F)
RELATIVE HUMIDITY	20 ~ 90% RH (no condensation)

Package Contents

• 1 x HDM-C6IP-S
• 1 x HDM-C6IP-R
• 2 x Power Adapter (+5VDC, 1A)
• 1 x User’s Manual
