HDMI Quad MultiViewer with Rotation, Chromakey and Audio

Introduction to HDM-SPLITPRO-4A-V2, successor to the HDM-SPLITPRO-4A, now with more optimized processing. This 4×1 Multiviewer Scaler was developed for the growing demand in security, video conference and sporting events.This 1U HDMI device can accept 4 HDMI input digital sources and then combine, (4) four video signals onto a single HDMI HD Monitor. The user can easily manage each input via the Menu settings and create any layout and position of any of the 4 (four) inputs on a single monitor. This device supports full range of video resolutions up to WUXGA@60 (RB) or Full HD1080p and audio supported up to 8-channel LPCM with 192 kHz sampling rate for both input and output. Audio channels can be selected to playback with input or can be muted.

• Seamless Switching, Fade In Out – This device can input any 4 HDMI input digital sources and then combine, (4) four video signals onto a single HDMI HD Monitor. The user will benefit from its processing power to seamlessly switch between the 8 different Hot key functions via IR remote, Telnet, Rs232 or front panel buttons.
• Zoom In/Out – This device can Zoom In/Out any 4 HDMI input digital sources and then combine, (4) four video signals onto a single HDMI HD Monitor. This device can be configured using the OSD, IR remote, Telnet, Rs232 or front panel buttons to set the desired layout configuration.
• PIP, POP, Overlay – This device can input any 4 HDMI digital sources and then combine, (4) four video signals onto a single HDMI HD Monitor. The user can select Picture In Picture (PIP), Picture on Picture (POP) or Overlay with the OSD, IR remote, Telnet, Rs232 or front panel buttons to set the desired layout configuration.
• Channel Size and Position – The user can easily change the individual channel size and choose different positions and layouts on the single monitor with the OSD, IR remote, Telnet, Rs232 or front panel buttons to set the desired layout configuration.
• Rotation (90 & 180) & Mirror – The user can easily rotate the image 90 degrees to the left or right and also mirror the image. This device can be configured with the OSD, IR remote, Telnet, Rs232 or front panel buttons to set the desired layout configuration.
• Chromakey – This device can input 4 HDMI digital sources but only utilize (2) two inputs for this technique (layering two images or video streams together based on color hues and chroma range). Where IN1 is the background and IN 2 is the top image. This device can be configured with the OSD, IR remote, Telnet, Rs232 or front panel buttons to set the desired layout configuration. This is commonly used in weather forecast broadcasts for example, a news presenter is usually seen standing in front of a large CGI map during live television newscasts, though in actuality it is a large blue or green background. When using a blue screen, different weather maps are added on the parts of the image where the color is blue. If the news presenter wears blue clothes, his or her clothes will also be replaced with the background video. A complementary system is used for green screens. Chroma keying is also used in the entertainment industry for special effects in movies and video games. The advanced state of technology and much commercially available computer software, such as Autodesk Smoke, Final Cut Pro, Pinnacle Studio, Adobe After Effects, and dozens of other computer programs, makes it possible and relatively easy for the average home computer user to create videos using the “Chromakey” function with HDM-SPLITPRO-4A.

Features

• Seamless switching and Fade In Out between input channels and combined images on single HD Monitor;
• Zoom In/Out the (4) four HDMI Input Channels;
• Supports PIP, POP, PAP and Multi-window layout configurations;
• Rotation (90 & 180) functions;
• Supports Chromakey Function;
• Mirror the (4) four HDMI Input Channels;
• 8 Preset Hot keys for easy control and design layouts;
• 4 Custom Favorite saved layout buttons via the IR Remote;
• Input/Output resolution supports a full range of video resolutions up to WUXGA@60 (RB) or Full HD1080p;
• Audio Supports LPCM 2CH, 6CH, 8CH/AC3/DTS/Dolby Digital Plus/Dolby TruHD & DTS-HD;
• Fine tuning and adjustments of contrast, brightness, saturation and hue;
• Auto EDID detection from the source;
• USB for Service Mode and Firmware upgrade;
• Supports OSD, RS-232, Telnet, IR remote and front panel buttons;
• Factory Reset feature;
• 1RU Size

Technical Specifications

ITEM	DESCRIPTION
UNIT	HDM-SPLITPRO-4A-V2
UNIT DESCRIPTION	4×1 HDMI Quad Multiviewer with Rotation and Chromakey
HDCP COMPLIANCE	Yes
VIDEO BANDWIDTH	225 MHz (6.75Gbps)
HDMI INPUT CABLE DISTANCE	Up to 10M/1080p@12 bits
HDMI OUTPUT CABLE DISTANCE	Up to 10M/1080p@8 bits
SUPPORTED RESOLUTIONS	PC -VGA, XGA (1024 x 768), SXGA (1280 x 1024), UXGA (1600 x 1200), WUXGA (1920 x 1200)
	480i/720p/1080i/1080p@60
AUDIO SUPPORT	LPCM 2CH, 6CH, 8CH/AC3/DTS/Dolby Digital Plus/Dolby TruHD; DTS-HD
INPUT	4 x HDMI19 Pin Female type connector	1 x RJ45/RS-232 1xMini USB service only
OUTPUT	1 x HDMI 19 Pin Female type connector
USB CONNECTOR	Type A Mini USB
RJ45 CONNECTOR	WE/SS 8P8C with 2 LED indicators
SWITCHING SPEED	±8 kV (air-gap discharge) ±4 kV (contact discharge)
WEIGHT	4.85 lbs
DIMENSIONS (L X W X H)	17.16″ x 10″ x 1.7″
POWER SUPPLY	12V/3A DC (US/EU standards, CE/FCC/UL certified)
POWER CONSUMPTION	18W
ENVIRONMENTAL
OPERATING TEMPERATURE	32~104 F (0~40 C)
STORAGE TEMPERATURE	-4~140 F (-20~60 C)
RELATIVE HUMIDITY	20~90% RH (no condensation)

Diagrams

Additional Guides

• HDM-SPLITPRO-4A-V2 User Guide
• HDM-SPLITPRO-4A-V2 Control Codes and IR Commands
• HDM-SPLITPRO-4A User Guide
• HDM-SPLITPRO-4A Control Codes and IR Commands
