Model: HDM2-SPLITPRO-T4K-V3

HDMI 2.0a 4K@60 QUAD MULTIVIEWER W/ROTATION & USB VIDEO CAPTURE

Combine 4 UHD 4K sources onto a single display simultaneously
Capture and stream 4K video directly via built-in USB 3.0
Customize layouts instantly with PIP, PAP, and crop options

$4,665.33

This 4 input x 2 output multiviewer was developed for the purpose of supporting higher input and output resolutions up to (4K@60) for multiple sources on a single screen

USB Capture: Connect to the built in USB 3.0 UHD video capture to output 4K video to a computer for recording or streaming
This HDMI device can accept 4 HDMI 4K input digital sources and combine (4) four video signals onto a single HDMI UHD or HD monitor The user can easily manage each input via the supplied Control Software and create any layout and position of any of the 4 (four) Inputs on a single monitor. This device supports full range of input video resolutions up to 4K with audio RCA breakout supported for external audio distribution systems. Audio channels can be selected to playback with input or can be muted.
Fast Switching – This device can input any 4 HDMI input digital sources and then combine, (4) four video signals onto a single HDMI UHD monitor. The user will benefit with from its processing power to switch between the 8 user defined function using control software via Ethernet or RS232, IR Remote.
Crop – This device can Crop any 4 HDMI input digital sources to remove black bars and then combine, (4) four video signals onto a single HDMI HD monitor. This device can be configured using the supplied Control software via Ethernet or RS232 to set the desired layout on the connected screens.
PIP, PAP, Overlay – This device can input any 4 HDMI digital sources and then combine, (4) four video signals onto a single HDMI HD monitor, which the user can select picture in picture (PIP), picture Aside picture (PAP) or overlay with the supplied Control Software via Ethernet or RS232 to set the desired layout configuration.
Window Scale and Position – The user can easily change the individual channel size and choose different position and layout on the single monitor with the Control Software via Ethernet or RS232 to set the desired layout configuration.
Scalable Rotation (90% & -90%) – The user can easily Rotate/Scale only a single input/window image 90? left and right. This device can be configured with the Control Software, IR Remote, Ethernet, RS232 or front panel buttons.

Features

4 HDMI 4K Inputs & 2 HDMI 4K Outputs (with one HDMI loop out up to 4K2K@60 (YUV 4:4:4) interlaced or progressive)
Output resolution support up to 4K@60 (3840×2160);
Output resolution support Full HD or to 4K@60 (3840×2160);
USB 3.0 FHD Video Capture, UVC 1.0
HDCP 1.4/2.2 compliant
Fast switching between input channels and combined multiple images on single UHD display;
Cropping the (4) four HDMI Input Channels;
Supports PIP, PAP and multi-windows layout configurations;
Single Input Rotation (90? left & right) functions;
Background picture & logo support
Resize, position, zoom & pan and blend output video
Fade-in-&-out, wipe and dissolve transitions in full screen mode
8 preset Hot keys with 4 Custom layouts and 4 Full screen layouts within the supplied control software;
4 Custom saved layout buttons via the IR Remote;
Input resolution support full range of video resolutions up to WUXGA@60 (RB) or full HD1080p;
Uncompressed 7.1ch digital over HDMI
USB-C port for Service mode and firmware upgrade;
Supports RS 232, Ethernet, IR Remote and front panel buttons.
Factory Reset feature.

Technical Specifications

Item	Description
UNITS	HDM2-SPLITPRO-T4K-V3
UNIT DESCRIPTION	HDMI 2.0a 4K@60 QUAD MULTIVIEWER W/ROTATION & USB VIDEO CAPTURE
HDCP COMPLIANCE	1.4, 2.2
VIDEO BANDWIDTH	HDMI 600MHz [18Gbps]
HDMI COMPLIANCE	HDMI 2.0a
VIDEO FORMAT SUPPORT	HDMI 2.0
INPUT SUPPORTED RESOLUTIONS	20p 50Hz, 720p 60Hz, 1080p 24Hz, 1080p 25Hz, 1080p 30Hz, 1080p 50Hz, 1080p 60Hz, 1920X1200 Hz, 3840×2160 60 Hz and 4K2K@60 (4:4:4 8bits)
OUTPUT SUPPORTED RESOLUTIONS	20p 50Hz, 720p 60Hz, 1080p 24Hz, 1080p 25Hz, 1080p 30Hz, 1080p 50Hz, 1080p 60Hz, 1920X1200 Hz, 3840×2160 60 Hz and 4K2K@60 (4:4:4 8bits)
USB VIDEO SUPPORT	Up to 4K2K@30
USB VIDEO FORMAT	YUY2 (USB3.0), MJPG (USB2.0/3.0)
USB CONNECTOR	USB 3.0 Type A (SuperSpeed USB)
AUDIO SUPPORT	LPCM
INPUT	4x HDMI + 1xRS-232 + 1x RJ-45(Ethernet) + 1x 3.5mm (IR)
OUTPUT	2x HDMI + 1x USB + 2x RCA + 1x 3.5mm
CONTROL	RS 232 / IP Control / IR / Front Panel
RJ45 CONNECTOR	WE/SS 8P8C with 2 LED indicators
ESD PROTECTION	Human body model: ±15kV [air-gap discharge] & ±8kV [contact discharge]
WEIGHT Unit Package	2.3 kg [5 lbs] 3.5 kg [7.8 lbs]
DIMENSIONS Unit Package	(L X W X H) 440 x 237 x 44mm [1’4″ x 9.3″ x 1.7″] 526 x 318 x 156mm [1’7″ x 12.5″ x 6.1″]
POWER SUPPLY	12V/5A DC (US/EU standards, CE/FCC/UL certified)
POWER CONSUMPTION	22W
