RS232 Transmitter over CAT5, Cascading Module for DVI-SPLITPRO-4X / DVI-SPLITPRO-4K

Model:  C5-RS232-S
Add to Wishlist

Description

Overview

The C5-RS232-S, RS232 Transmitter over CAT5, Cascading Module for DVI-SPLITPRO-4X /  DVI-SPLITPRO-4K  C5-RS232-S offers the ability of cascading; the remote units can be cascaded up to 32  devices.



Features

  • Sends RS-232 data up to 1,000m (1,100yds)
  • Real time pure hardware solution
  • Extra RJ-45 for cascading
  • Compact size
  • C5-RS232-S  offers the ability of cascading; the remote units can be cascaded up to 32  devices.

Technical Specification



ITEM

DESCRIPTION

UNIT

C5-RS232-S

UNIT DESCRIPTION

RS232 Transmitter over CAT5, Cascading Module for DVI-SPLITPRO-4X /  DVI-SPLITPRO-4K

OUTPUT

1x RJ-45

INPUT

1x RS-232

BAUD RATE

Up to 57.6kbps in cascade mode

RS232 CONNECTOR

DE-9 (9-pin D-sub female)

RJ45 CONNECTOR

WE/SS 8P8C with 2 LED indicators

DIP SWITCH

6-pinD  & audio mode [SW Main] 6-pin operation & firmware update

RJ45 CONNECTOR

WE/SS 8P8C with 2 LED indicators

DIMENSIONS

2.5″ x 1.9″ x 1.4″

POWER SUPPLY

5V 2A DC

POWER CONSUMPTION

1 Watts (max)

ENVIRONMENTAL

OPERATING TEMPERATURE

0~40°C [32~104°F]

STORAGE TEMPERATURE

-20~60°C [-4~140°F]

RELATIVE HUMIDITY

20~90% RH [no condensation]

Package Contents

  • 1 x C5-RS232-S
  • 1 x  Power Adapter
  • 1 x User’s Manual



No Diagram Available

User Guides

For Cascading instructions please refer to cascading section in User Guide below

Avenview Advanced Quad Screen Video Processor User GuideDVI-SPLTIPRO-4X User Guide

Avenview Advanced Quad Screen Video Processor User GuideDVI-SPLTIPRO-4KUser Guide

No video is aivalable

Please Contact Us

FAQ Warranty & RMA Product Registration Avenview Tech Support

Additional information

Weight 0.91 kg
