Name: SCALERPRO - HDMI Scaler 4K@60 with EDID Manager
SKU: 975
Price: 299.00 USD
Availability: InStock

The SC-HDM2-T4KHD scaler with HDMI 2.0a and HDCP 2.2 Support is a device that can solve EDID (Extended Display Identification Data) information problems within any system design when different devices with varying resolutions are connected. With its own control software supplied the user can simply store and recall a default EDID information, also supporting EDID Re-timer / EDID Recorder setting in non-volatile memory and supports HDCP handshaking.

SC-HDM2-T4KHD allows HDMI source to boot directly from EDID Reader/Writer/Re-timer mode. This feature allows the user to easily remove the monitor at any time while installing SC HDM2-T4KHD between HDMI source and monitor. Also using the control software user can read, store and modify the EDID of any HDMI/DVI display upload the modified EDID to displays.

The SC-HDM2-T4KHD has the abilty to handle many different chroma sampling such as 4:2:0, 4:2:2 and 4:4:4.

Features

• HDMI 2.0a compliant;
• Supports 4K2K@60 4:4:4 8bits;
• Supports HDR, which is 4K2K@60 4:2:0 10bits;
• HDCP 2.2 compliant;
• Supports resolution upscaling from 1080p to 4K2K or downscaling from 4K2K to 1080p (No frame rate conversion);
• Supports HDMI signal bypass;
• Simultaneous HDMI output;
• Able to read and store the EDID of displays (monitors or projectors);
• Able to overwrite the EDID into the EDID Reader/Re-timer or the HDMI displays;
• Built-in default EDID;
• Able to maintain HDMI/DVI video resolution;
• Re-synthesizes input HDMI stream and maintains or improves signal integrity;
• 1080i and 720p scaling not supported. 1080i and 720p bypass supported;
• PC Software required to assign HDMI ports to upscale, downscale or bypass

Specifications

ITEM	DESCRIPTION
UNIT	SC-HDM2-T4KHD
UNIT DESCRIPTION	EDID Manager With HDCP 2.2 Support
SUPPORTED RESOLUTION	HDR 4K2K@24/25/30/50/60 (3840×2160)(4:2:0 10bits) / 4K2K@24/25/30/50/60 (3840×2160) (4:4:4 8bits), 1920x1080p@24/25/30/50/60, bypass only: 720x480p, 720x576p, 1280x720p
HDMI COMPLIANCE	HDMI 2.0a
INPUT PORTS	1x HDMI, 1x mini-USB
OUTPUT PORTS	2x HDMI
HDCP VIDEO COMPLIANCE	2.2
HDMI CONNECTOR	Type A [19-pin female]
DIGITAL AUDIO SUPPORT	5.1/7.1 Lossless Dolby TrueHD and DTS-HD Surround Sound
USB CONNECTOR	Type mini-USB
FLASH EEPROM	256 bytes [non-volatile]
CONTROL	USB
HDR SUPPORT	Yes
EDID MODES	7 Adjustable Modes
HDMI OUT OPTIONS	OUTPUT 1: Bypass – Upscale to 4K OUTPUT 2: Bypass – Downscale to 1080p
VIDEO BANDWIDTH	Single-link 600MHz [18Gbps]
CHROMA SAMPLING	4:2:0, 4:2:2 and 4:4:4
POWER SUPPLY	5V 2A
POWER CONSUMPTION	4 W
DIMENSIONS (L X W X H)	3.7” x 3.2” x 1”
WEIGHT	0.6 lbs
*ENVIRONMENTAL*
OPERATING TEMPERATURE	32° ~ 104°F (0° to 40°C)
STORAGE TEMPERATURE	-4° ~ 140°F (-20° ~ 60°C)
ESD PROTECTION	Human body model — ±8kV (air-gap discharge) & ±4kV (contact discharge)
RELATIVE HUMIDITY	20~90% RH (no condensation)
