Description

Product Details

Overview

The C6-USB-50M is a high performance USB 2.0 extender, compliant with USB 2.0 specifications (up to 480Mbps). With this device you can extend the transmission distance between any USB device and the computer up to 50 meters, eliminating the 5 meters distance limitation of regular USB.

Features

•Support for any High-Speed (480Mb/s), fullspeed (12 Mb/s) or low-speed (1.5 Mb/s)
USB devices;
Extends USB device cable length up to 50m;
Supports suspend/resume detection;
Supports Hot Plug;
Cost effective in comparison with extension of cable using hubs or other USB extender;
No software driver required;
Supports Windows XP/Vista/7/8.

Specifications

Item	Description
UNITS	C6-USB-50M
UNIT DESCRIPTION	HDBaseT HDMI Modular Matrix Switcher with IR/RS232/POE/4k2k support
LOCAL UNIT	Upstream Port, Downstream Port, Power, USB Type A Male, RJ45 Jack, Bus-Powered
REMOTE UNIT	Upstream Port, Downstream Port, Power, USB Type A Female, RJ45 Jack, Self-Powered
BUILT IN CABLE LENGTH	1 Feet
INTERCONNECT CABLE	Standard Category-5/5e/6 Network Cable
MAX CABLE LENGTH	50m
OPERATING TEMPERATURE	0?~55?
POWER SUPPLY	5V/2A
DIMENSIONS (L x W x H)	2.5” X 1.4” X 1”
NET WEIGHT	0.8 lbs
