Model: HDM-AVXWALL-XX

XXX-AVXWALL

4K Video Wall Processor, FPGA Fully Customizable with Hot Swappable Cards

/*! elementor – v3.6.5 – 27-04-2022 */
.elementor-heading-title{padding:0;margin:0;line-height:1}.elementor-widget-heading .elementor-heading-title[class*=elementor-size-]>a{color:inherit;font-size:inherit;line-height:inherit}.elementor-widget-heading .elementor-heading-title.elementor-size-small{font-size:15px}.elementor-widget-heading .elementor-heading-title.elementor-size-medium{font-size:19px}.elementor-widget-heading .elementor-heading-title.elementor-size-large{font-size:29px}.elementor-widget-heading .elementor-heading-title.elementor-size-xl{font-size:39px}.elementor-widget-heading .elementor-heading-title.elementor-size-xxl{font-size:59px}

Please Choose:

Model: HDM-AVXWALL-2X4 (2 Inputs/4 Outputs) Processor ( +$13,536.50USD ) HDM-AVXWALL-2X6 (2 Inputs/6 Outputs) Processor ( +$15,634.00USD ) HDM-AVXWALL-4X4 (4 Inputs/4 Outputs) Processor ( +$14,784.00USD ) HDM-AVXWALL-4X6 (4 Inputs /6 Outputs) Processor ( +$16,881.50USD ) HDM-AVXWALL-4X8 (4 Inputs / 8 Outputs) Processor ( +$18,979.00USD ) HDM-AVXWALL-4X12 (4 Inputs/ 12 Outputs) Processor ( +$24,874.00USD ) HDM-AVXWALL-4X16 (4 Inputs / 16 Outputs) Processor ( +$29,069.00USD ) HDM-AVXWALL-6X6 (6 Inputs / 6 Outputs) Processor ( +$18,129.00USD ) HDM-AVXWALL-6X12 (6 Inputs / 12 Outputs) Processor ( +$26,121.50USD ) HDM-AVXWALL-6X16 (6 Inputs / 16 Outputs) Processor ( +$30,316.50USD ) HDM-AVXWALL-8X8 (8 Inputs / 8 Outputs) Processor ( +$21,474.00USD ) HDM-AVXWALL-8X12 (8 Inputs / 12 Outputs) Processor ( +$27,369.00USD ) HDM-AVXWALL-8X16 (8 Inputs / 16 Outputs) Processor ( +$31,564.00USD ) HDM-AVXWALL-12X12 (12 Inputs / 12 Outputs) Processor ( +$29,864.00USD ) HDM-AVXWALL-16X16 (16 Inputs / 16 Outputs) Processor ( +$36,554.00USD ) HDM-AVXWALL-32X32 (32 Inputs / 32 Outputs) Processor ( +$72,914.00USD ) HDM-AVXWALL-32X36 (32 Inputs / 36 Outputs) Processor ( +$77,109.00USD )

Starting at: $13,536.50USD

MCROSITE

PRODCUTS DETAILS
DIAGRAM
USER GUIDE
MULTIMEDIA
SOFTWARE
SUPPORT
MICROSITE

Overview

The Avenview AVXWALL is a modular chassis based, 4K video wall processor that has video processors built into the design. It is the first in its class FPGA and the first to be industry recognized. During Avenview’s 8 years in the Video Wall industry, we have developed a very reliable hardware design and stable system design with unprecedented flexibility on the input and output cards. The AVXWALL is compatible with standard definition (SD), Full HD (1080p), WQXGA (2160×1600) and 4K. This device can accept 4K signal formats with modular input and output board design with video connectors such as, Dual Link DVI, DisplayPort and HDMI which offer impeccable quality across multiple screens. The video wall processor can also mix and match our line of I/O cards which can be installed into the appointed space. I/O cards are available in CVBS, YPbPr, VGA, DVI, HDMI, SDI, DisplayPort, HDBASET and optical fiber. These I/O cards offer extremely high video bandwidth, which ensures real-time signal processing, with no delay or frame loss. The unit is equipped with a separate DVI port for real time monitoring to an external monitor at 60fps with no frame loss. No in-depth training is required to use our new Control Software. Creative and useful features for any client solution include, drag and drop; image placement; zoom; and user preset buttons to recall favorites. Bonus feature; our software can also preview the input source directly within the Control Software which is connected through TCP/IP. Enjoy using your touch devices with our optional automation linux based controller to manage multiple video walls and layouts with fully customizable interface. It also supports a 2×2, 3×3 and 4×4 -16 grid format on a single display with the click of a mouse. Having FPGA as its core design, this technology enables this unit to manage multiple video walls with one single processor. The user has the ability to control each video-wall separately within the control software. The output resolution can also be managed within each individual screen/monitor and also for different video walls.

Features

Modular input and output chasis design 720×480 to 4096×2160 with a local DVI loop out for monitoring;
Supports CVBS, YPbPr, VGA, DVI, HDMI, SDI, DisplayPort, UTP and optical fiber;
Full screen modes, zoom, image crop and adjustable size & position through software;
Functions perfectly as a multi-viewer, video screen splitter, video converter and matrix switcher;
Single screen grid formatting 2×2, 3×3, 4×4;
Minimum single screen to 64 screens horizontally/32 screens vertically 600×800, 768×1024, 768×1024, 720×1280, 800×1280, 1024×1280, 768×1366, 768×1360, 1050×1400, 900×1440, 1200×1600, 1050×1680, 1080×1920, 1200×1920;
Image parameters and layouts are automatically saved in the Preset Mode of the device creating easy buttons;
Background Image storage;
Management of Multiple Video Walls;
EDID Management;
Input Signal preview through Control Software;
Software control through TCP/IP;
2/4/8/13U size

Technical Specification

ITEM	DESCRIPTION
UNIT	HDM-AVXWALL
UNIT DESCRIPTION	Multi-Input Image Video Wall processor with 4K support
VIDEO FORMAT SUPPORT	CVBS,YPbPr,VGA,DVI, HDMI, SDI, DisplayPort,UTP and optical fiber;
LOCAL OUTPUT	Yes DVI
SUPPORTED RESOLUTION	SD Up to 1080p, 4K (4096×2160@24Hz)
AUDIO SUPPORT	No
SYSTEM CONTROL	TCP/IP
ESD PROTECTION	Human body model – ? 15kV (air gap discharge) & ±8kV (contact discharge
INPUT	4 x CVBS Component-720×576?PAL?720×480?NTSC? 4 x RGBHV/YPbPr- 1920×1200@60Hz 4 x DVI- D digital T.M.D.S signal in DVI 1.0 1920×1200@60Hz
	4 x HDMI 1920×1080/1920×1200@60Hz
	8 x SDI SMPTE 259M/292M/424M 1920x1080p
	2 x Dual -Link DVI 4096×2160@24Hz, 3840×2400@30Hz, 2560×1600@60Hz
	2 x Displayport 4096×2160@24Hz, 3840×2400@30Hz, 2560×1600@60Hz
	4 x HDBaseT 1920×1080/1920×1200@60Hz
OUTPUT	4 x DVI- I 1920×1200@60Hz
	4 x HDBaseT 1920×1080/1920×1200@60Hz
	2 x Dual -Link DVI 4096×2160@24Hz, 3840×2400@30Hz, 2560×1600@60Hz
	2 x HDMI 4096×2160@24Hz, 3840×2400@30Hz, 2560×1600@60Hz
DVI CONNECTOR TYPE	DVI-I (29-Pin female)
RJ45 CONNECTOR	WE/SS 8P8C with 2 LED indicators
DIMENSION I/O CARDS	2U 4 I/O SLOTS 482 x 88 x 380 2380 (L x W x H)
POWER SUPPLY	AC 100-240V
POWER CONSUMPTION	150 Watts (max)
*ENVIRONMENTAL*
OPERATING TEMPERATURE	0~40°C [32~104°F]
STORAGE TEMPERATURE	-10~60°C [14~140°F]
RELATIVE HUMIDITY	20~90% RH [no condensation]

Package Contents

1 x Videowall Processor
2 x Rack-mounting Kit
1 x UL AC Power Cord
1 x Installation Software CD
1 x User’s Manual
